1/2″ Valve 1234yf A/C Recharge Hose with Gauge – 13″ / 33 cm – 45763

The heavy duty Recharge Hose with Pressure Gauge is suitable for all Emzone 1234yf Refrigerant products. Use to determine current pressure status of A/C system and ensure accuracy when recharging. The durable brass connectors ensure a safe and secure fit. Low side port 1234yf connector.

*Available in bulk without packaging – Item no. 45753

ITEM NUMBER   45763

PRODUCT SIZE   1/2” Tap
UPC NUMBER   060480 457633


IMPORTANT:
Always wear safety eyewear when servicing your air conditioning system.
USE ONLY on low side service port. DO NOT CONNECT to high side service port of system as this could result in serious injury.

Instructions:
1. Always connect to low side service port.
2. Refer to can for further instructions before using.
3. Connect tap end of hose to can and attach connector end to low side service port.
4. Ensure a secure fit at both ends of hose.
5. Turn hose tap clockwise to puncture top.
6. Turn hose tap counter-clockwise to begin flow of refrigerant.
7. Remove hose when finished and replace blue protective cap on service port.
